Default Battery dealer installs 3-wheeler battery in my car!! Now what?

I own a Chevrolet Beat 2011 Petrol. The stock battery was Exide 12v 50 AH.

The car had showed symptoms of the battery dying. During the scheduled service 2 months back, it went dead while I was taking the delivery.

This time, while returning from a trip from Mysore, on the Bangalore-Mysore highway, the car went dead, after I had stopped for a tea break. I managed to get a mechanic, who jump started it and I drove for around 10 kms where the car went dead again all of a sudden in the middle of traffic. I had my headlights and all other electrical devices switched off to save battery power, but it went dead just like that.

The MID lights were faint and flashing. I managed to locate a battery dealer who dealt in Amaron batteries.

After speaking to him on phone, he came in 15 mins with a new battery. But the specification of that battery was 12v 35 AH. He went back and got another battery which was 12v 65 AH (as compared to 50 AH of my stock battery).

The only grouse was that the battery wouldn't fit in completely in the engine bay. He had to remove the grounding wires and re-connect at a different point so as to get some extra length of the wiring harness to connect to the battery.

It was late evening around 9:30 PM and although I managed to notice the battery model, I didn't notice the sticker which said that it was "For 3 Wheelers Only".
More scary, it does not feature on the Amaron website !!

I enquired with a couple of my Team-BHP friends on phone and they said that it was okay, as long as the cranking voltage comes to more than 12v.

The shopkeeper / mechanic tested the voltage of both the batteries.
My old stock Exide showed 9.6v or so.
The new Amaron battery showed 12.85v.

The battery is running fine now and I am able to notice certain improvements like:
- Car starts in one go without 2nd attempt.
- Power windows roll up faster in Ignition stage (engine off).
- After cranking the engine, the stock music player starts immediately (earlier, it used to take about 5-6 seconds to start playing).
- At slow speeds, car doesn't stall even if I don't use clutch much. Earlier, it would jerk and the engine would switch off.

So now the scene is:
Stock Battery: Exide 12v 50AH
New Battery: Amaron Black BL600LMF


However, there are something which are still making me worried.

Hence posting it here for advice:

- The battery output is 12v, which is okay for my car. Then why does it say "For 3 Wheelers Only" ? What is the difference here ?

- Would this cause any overloading of the wiring harness or electricals of the car ?

- The holding clamp of the old battery doesn't fit the new one since this one is bigger in dimension. It is snugly fit, so do I still need to fabricate a clamp to hold it more firmly.

- Since this is a bigger battery, it weighs more as well. Would it cause any major change in the car dynamics, or overload the LHS suspension or some mechanical parts ?

I am planning to take it to an Amaron dealer sometime this weekend, and get it checked. If at all they say that this is not the correct one (in terms of size & weight) for the car, and have the correct replacement in stock, should I exchange it with them ? What will be the probable buy-back price that I may expect for this new battery ?

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150525_153745.jpg

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150525_153829.jpg

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150528_071919.jpg

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150528_072019.jpg

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150528_071956.jpg

Battery dealer installs 3-wheeler battery in my car!! Now what?-20150528_071948.jpg

Mods: Posting this as a new thread for more visibility and quick advice. If deem fit, kindly move or merge.

Last edited by Soumyajit9 : 28th May 2015 at 09:56.
Soumyajit9 is offline   (11) Thanks Reply With Quote
Old 28th May 2015, 10:00   #2
Distinguished - BHPian

dhanushs's Avatar

Join Date: Oct 2009
Location: Bathery/BLR
Posts: 3,446
Thanked: 4,057 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Soumyajit9 View Post
- The battery output is 12v, which is okay for my car. Then why does it say "For 3 Wheelers Only" ? What is the difference here ?

- Would this cause any overloading of the wiring harness or electricals of the car ?
Nowadays, its always 12v. Only the amperage varies. Its OK to put a 65ah battery in place of a 50 ah one. The only difference it will make is a 30% longer time for the battery to attain full charge, with the current alternator and load set up.

Quote:
- The holding clamp of the old battery doesn't fit the new one since this one is bigger in dimension. It is snugly fit, so do I still need to fabricate a clamp to hold it more firmly.

- Since this is a bigger battery, it weighs more as well. Would it cause any major change in the car dynamic, or overload the LHS suspension or some mechanical parts ?
This is where you HAVE to make sure, its done right. An incorrectly placed battery is very dangerous. Jerks, or if it falls, can lead to even explosions. Please make sure the fitment is snug, and the battery is properly damped, so that the plastic walls doesnt wear out over a period of time and cause leaks.

I'd say - anyhow you've bought this battery. So, fabricate a proper mount for it, and use it.
dhanushs is offline   (11) Thanks Reply With Quote
Old 28th May 2015, 10:09   #3
BHPian

purohitanuj's Avatar

Join Date: May 2015
Location: New Delhi
Posts: 124
Thanked: 234 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

I think that this should be just fine; a thumb rule for battery upgrades says that you should not exceed 15 A/h in addition to the stock rating.
A/h is basically measurement of the battery's "capacity" and is often measured in Cold Crank Amps.
The disadvantages that I can think are:
1. If drained completely, it will take some more time (relative to stock) to completely charge
2. Some warranty issues (but not sure).
purohitanuj is offline   (6) Thanks Reply With Quote
Old 28th May 2015, 13:07   #4
Team-BHP Support

Jaggu's Avatar

Join Date: May 2004
Location: Bangalore
Posts: 17,752
Thanked: 7,478 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Soumyajit9 View Post
So now the scene is:
Stock Battery: Exide 12v 50AH
New Battery: Amaron Black BL600LMF

- The battery output is 12v, which is okay for my car. Then why does it say "For 3 Wheelers Only" ? What is the difference here ?
Will take more daily crank cycles according to marketing info out there. So technically more good for stop and go traffic.

Quote:
- Would this cause any overloading of the wiring harness or electricals of the car ?
15 Amp easily will be accommodated by the alternator.

Quote:
- The holding clamp of the old battery doesn't fit the new one since this one is bigger in dimension. It is snugly fit, so do I still need to fabricate a clamp to hold it more firmly.
If you ask me this would be my biggest worry. In my old swift also i had the AH upgraded while changing. Good thing was only the terminal wire needed to be connected to another spot. The clamps were spot on.

Battery needs to be safely anchored for safety as well as longevity.

Quote:
- Since this is a bigger battery, it weighs more as well. Would it cause any major change in the car dynamics, or overload the LHS suspension or some mechanical parts ?
Difference would be marginal in weight.

Quote:
I am planning to take it to an Amaron dealer sometime this weekend, and get it checked. If at all they say that this is not the correct one (in terms of size & weight) for the car, and have the correct replacement in stock, should I exchange it with them ?
If it fits proper, don't bother.

Quote:
What will be the probable buy-back price that I may expect for this new battery ?
Depends on the dealer, generally they will try to make a quick buck. So expect minimum 1000 bucks. Hence not really worth it.

Also if you are particular use the original dealer to get the exchange.
Jaggu is offline   (7) Thanks Reply With Quote
Old 28th May 2015, 13:48   #5
BHPian

ilangop's Avatar

Join Date: Jul 2008
Location: Pune/Neyveli
Posts: 913
Thanked: 578 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Soumyajit9 View Post
He went back and got another battery which was 12v 65 AH (as compared to 50 AH of my stock battery).
So now the scene is:Stock Battery: Exide 12v 50AH
New Battery: Amaron Black BL600LMF
Soumyajit, You have no reason to worry at all. The new battery is suitable, if not of a higher charge capacity than the old one. This is how you decode the model number
BL - Black (I think so)
600 - Cold Cranking Current, could have been 500 Ampere with the old battery. Hence the starter motor can ramp up speed still quickly
L - Left side. Means, looking the battery with the battery terminals to your side the -ve terminal is on the left hand side
MF - Maintenance Free
Battery dealer installs 3-wheeler battery in my car!! Now what?-20150528_071956.jpg
So BL600RMF is the same battery with the terminal positions swapped
Quote:
- The battery output is 12v, which is okay for my car. Then why does it say "For 3 Wheelers Only" ? What is the difference here ?
Could be because of an odd sized battery tray which you may not find commonly on cars. Also, looking at the picture above, all the examples where this battery is used are long stroke single cylinder Diesels which need a lot of current initially to crank the engine. Your engine is multi-cylinder and hence the motor wouldn't draw as much peak current. So your are not using the new battery to its full capacity.

Quote:
- Would this cause any overloading of the wiring harness or electricals of the car ?
Not at all, as the Ah is just marginally higher than the old one. Just the alternator might take little more time to full charge the battery.

Quote:
-The holding clamp of the old battery doesn't fit the new one since this one is bigger in dimension. It is snugly fit, so do I still need to fabricate a clamp to hold it more firmly.
Take suggestion from a mechanic and buy a battery of clamp of another car of similar battery size. Saves you from looking for a fabricator and paying him more.

Quote:
-Since this is a bigger battery, it weighs more as well. Would it cause any major change in the car dynamics, or overload the LHS suspension or some mechanical parts ?
It would have added hardly 3-4 kgs over the old battery. Just as much as 2X2.25 litre pepsi bottles, don't worry.

Last edited by ilangop : 28th May 2015 at 13:50.
ilangop is offline   (7) Thanks Reply With Quote
Old 28th May 2015, 13:51   #6
BHPian

purohitanuj's Avatar

Join Date: May 2015
Location: New Delhi
Posts: 124
Thanked: 234 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Jaggu View Post
W..15 Amp easily will be accommodated by the alternator...
It’s not an additional load (of 15 ampere!) on the alternator. You can charge a 12 volt battery from different current source like 14v @ 1 Amp or 14v@20 Amp.
The ampere of charger would relate to the speed in which the battery charges. Battery cannot draw specific amperes directly.

However once it is charged, it is capable of delivering 12volts @ 15 ampere for 1 hour (for a 15 A/h battery) before the voltage starts to drop.
This also means that you may draw 12V@30 amperes but the battery may provide 12 volt for 30 minutes only; after which the voltage will drop.

Say you have an inverter at home which uses 12volt battery. Then you may combine 2-3-4 batteries in parallel which will not smoke your inverter but take much more time to charge them (and last much longer).

Last edited by purohitanuj : 28th May 2015 at 13:55. Reason: clarity
purohitanuj is offline   (3) Thanks Reply With Quote
Old 28th May 2015, 13:51   #7
Senior - BHPian

theexperthand's Avatar

Join Date: Oct 2008
Location: Bangalore
Posts: 1,369
Thanked: 1,136 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

If you still is not convinced (after reading the above detailed replies), do make a call to the customer care to check if there is any adverse effects (I personally think you will be perfectly fine with the current battery).

Change in weight will be marginal, but do make sure that the battery is properly secured. Use additional clamps \ mounting brackets and use old rubber tube to sandwich the clamps and battery.

--Anoop
theexperthand is offline   (2) Thanks Reply With Quote
Old 28th May 2015, 13:57   #8
BHPian

shifu's Avatar

Join Date: Aug 2014
Location: Hyderabad
Posts: 399
Thanked: 351 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Soumyajit9 View Post
- At slow speeds, car doesn't stall even if I don't use clutch much. Earlier, it would jerk and the engine would switch off.
Sorry, I don't have much idea about your predicament. However, I am stuck at your above sentence. How does having a bigger battery (interms of AH) help in not stalling a car at slow speeds? Is this just psychological or really true?
shifu is offline   Reply With Quote
Old 28th May 2015, 14:30   #9
Senior - BHPian

Soumyajit9's Avatar

Join Date: Oct 2012
Location: 10010
Posts: 1,501
Thanked: 1,665 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Thanks everyone for the re-assurance that eveything should be fine with the electricals.
From the mechanical point of view, since the old clamp doesn't hold and it is not safe to run with an untagged battery, I would speak to the fabricator behind my house (he deals with window grills and stuff), to fabricate a clamp for the battery.

One last, kinda silly question - It is okay if I leave that plastic wrapping on the battery ? Won't it melt gradually with the engine heat ? Or should I carefully remove it completely ?

Will anyways go to a Bangalore dealer this weekend to verify everything.

Thanks once again everyone.

Quote:
Originally Posted by shifu View Post
Sorry, I don't have much idea about your predicament. However, I am stuck at your above sentence. How does having a bigger battery (interms of AH) help in not stalling a car at slow speeds? Is this just psychological or really true?
It is mostly because of the old battery life. The earlier battery was end of life and no charge left. So a little mis-management of clutch used to cut off power to the engine, mechanically and electrically.

Now, the new battery holds the power steady to the components I guess. Because of this even at low speeds, even though clutch is mis-managed, the battery holds up the electrical power to the components. Not related to the bigger AH thing. Just a new battery.
Soumyajit9 is offline   (1) Thanks Reply With Quote
Old 28th May 2015, 14:41   #10
BHPian

purohitanuj's Avatar

Join Date: May 2015
Location: New Delhi
Posts: 124
Thanked: 234 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by shifu View Post
Sorry, I don't have much idea about your predicament. However, I am stuck at your above sentence. How does having a bigger battery (interms of AH) help in not stalling a car at slow speeds? Is this just psychological or really true?
Its true and much more noticeable in petrol engines (and much more in CNG/LPG) . If you have a bad battery which is always a load on the alternator (which is a load on engine), then during initial pickup, you will get lesser grunt than usual.

I learned this when we had a petrol genset(with battery and charger) which used to struggle as soon as the compressor of fridge started and would die out because of the lack of immediate torque required to turn the alternator. This was solved by replacing the battery. As diesels have huge torque available in lower revs, thus this problem is not noticeable.
purohitanuj is offline   (6) Thanks Reply With Quote
Old 28th May 2015, 14:42   #11
Senior - BHPian

DerAlte's Avatar

Join Date: Mar 2007
Location: Bangalore
Posts: 8,076
Thanked: 2,876 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Check the charging characteristics - ask Amaron if they can share that with you. The only difference between batteries for larger engines / vehicles and 3-wheelers / small LCVs is the alternator rating - and hence the charging current. This battery may be designed with a different charging profile. The only impact is on the average temperature of the battery - you might need get the electrolyte level checked once in a while.
DerAlte is offline   (5) Thanks Reply With Quote
Old 28th May 2015, 14:45   #12
Team-BHP Support

Jaggu's Avatar

Join Date: May 2004
Location: Bangalore
Posts: 17,752
Thanked: 7,478 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by purohitanuj View Post
It’s not an additional load (of 15 ampere!) on the alternator. You can charge a 12 volt battery from different current source like 14v @ 1 Amp or 14v@20 Amp.
Ok!! to clarify having an additional 15 amp at battery end, wires would not overload (Original question that i have replied to). Only alternator which would be designed for the 50 amp would take more time to charge and that is not an issue (my answer).

Last edited by Jaggu : 28th May 2015 at 14:47.
Jaggu is offline   (4) Thanks Reply With Quote
Old 28th May 2015, 15:05   #13
Senior - BHPian

sandeepmohan's Avatar

Join Date: Feb 2010
Location: Wellington
Posts: 1,944
Thanked: 1,626 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Two months is quite a bit to attend to a weak battery. I feel you should have replaced it much sooner, especially when it died when you were taking your car back from service. All of this caused inconvenience to you, your family and a safety hazard as you were driving without lights. It is not worth it. Please attend to the needs of the car in time.
sandeepmohan is offline   (5) Thanks Reply With Quote
Old 28th May 2015, 15:12   #14
Senior - BHPian

Soumyajit9's Avatar

Join Date: Oct 2012
Location: 10010
Posts: 1,501
Thanked: 1,665 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by DerAlte View Post
Check the charging characteristics - ask Amaron if they can share that with you. The only difference between batteries for larger engines / vehicles and 3-wheelers / small LCVs is the alternator rating - and hence the charging current. This battery may be designed with a different charging profile. The only impact is on the average temperature of the battery - you might need get the electrolyte level checked once in a while.
Yes, will take it to a Bangalore dealer who would have more knowledge on this type of battery.
I don't think I need to check the electrolyte level. This is a zero maintenance battery with a black casing.

Quote:
Originally Posted by sandeepmohan View Post
Two months is quite a bit to attend to a weak battery. I feel you should have replaced it much sooner, especially when it died when you were taking your car back from service. All of this caused inconvenience to you, your family and a safety hazard as you were driving without lights. It is not worth it. Please attend to the needs of the car in time.
True Sandeep. I was very terrified with this issue.
I had my dad and mom with me. Dad had underwent Angioplasty exactly a year back and he had to assist me to move the car, run around with me searching for help. Lesson learnt the hard way. Would be careful about any such indications of failure !

Quote:
Originally Posted by ilangop View Post
This is how you decode the model number
BL - Black (I think so)
Yes, it indeed stands for Black. Found some FAQs about Amaron.

Quote:
- We were the first to introduce Zero Maintenance batteries for automotive applications in India.
- We were the first to introduce non-white battery casing; after all our batteries do not require topping up!
That explains why the battery casing is black and hence the series name.

Last edited by Gannu_1 : 31st May 2015 at 22:29. Reason: Corrected typo.
Soumyajit9 is offline   (3) Thanks Reply With Quote
Old 28th May 2015, 15:27   #15
BHPian

ilangop's Avatar

Join Date: Jul 2008
Location: Pune/Neyveli
Posts: 913
Thanked: 578 Times
Default re: Battery dealer installs 3-wheeler battery in my car!! Now what?

Quote:
Originally Posted by Soumyajit9 View Post
One last, kinda silly question - It is okay if I leave that plastic wrapping on the battery ? Won't it melt gradually with the engine heat ? Or should I carefully remove it completely ?
Remove the polythene cover completely as it would affect the heat dissipation from the battery. It won't melt away as you fear.
Usually window grill makers tend to overdesign such brackets. So insist on making the bracket / clamp with a material of just enough thickness.
ilangop is offline   (3) Thanks Reply With Quote
Reply


Thread Tools Search this Thread
Search this Thread:

Advanced Search


Similar Threads
Thread Thread Starter Forum Replies Last Post
3 wheeler for the price of a 4 wheeler, WHY? raj_5004 Commercial Vehicles 20 28th February 2012 11:27
2 Wheeler or 4 Wheeler? That is the question... mmxylorider Street Experiences 2 17th August 2010 23:08
2 Seater - Four Wheeler from VW - At the cost of a Two Wheeler!! Chethan B G The International Automotive Scene 4 11th May 2010 20:03
Bad Installs... gunbir In-Car Entertainment 179 24th July 2009 01:17
some nice installs. navin In-Car Entertainment 8 23rd February 2008 21:48


All times are GMT +5.5. The time now is 03:21.

Copyright 2000 - 2017, Team-BHP.com
Proudly powered by E2E Networks
